This application note contains six circuits that extend the LTC2400's capabilities using a number of low-cost components. These circuits include: high-accuracy differential-to-single-ended converter, simple differential front-end, bipolar input 24-bit A/D converter, high-accuracy differential-to-single-ended converter, differential input 24-bit A/D converter.
The document is an application note titled 'A Collection of Differential to Single-Ended Signal Conditioning Circuits for Use with the LTC2400'. It details six specific circuits designed to extend the capabilities of the LTC2400, a 24-bit No Latency Delta-Sigma ADC. These circuits allow for signal conditioning of differential inputs ranging from as low as 5mV up to ±2.5V.
It contains six circuits that extend the LTC2400's capabilities using low power differential-to-single-ended signal conditioning.
The circuits are designed to condition differential input signals as low as 5mV to as high as ±2.5V.
