The AD8401 is a complete data acquisition and control system containing ADC, DAC, 4-channel MUX, and internal voltage reference. It offers high package density and reliability, with conversion times as short as 2us and an analog input bandwidth of 200kHz.
The AD8401 is a complete data acquisition and control system containing an 8-bit successive approximation ADC with track/hold, an 8-bit DAC, a 4-channel multiplexer, and an internal voltage reference. Built using CBCMOS technology, it offers high package density and reliability for applications such as servo controls and process equipment.
| Resolution | 8 Bits |
|---|---|
| ADC Conversion Time | 2 µs |
| DAC Output Settling Time | < 4 µs |
| Analog Input Bandwidth | 200 kHz |
| Supply Voltage | +5 V |
| Operating Temperature Range | -40 °C to +85 °C |
The device features an 8-bit successive approximation ADC.
Yes, it is designed for direct interface to the AD899 hard-disk drive read-channel device.
The logic input low voltage is 0.8 V and high voltage is 2.4 V.
