The TPS40060 and TPS40061 are high-voltage, wide input (10 V to 55 V) synchronous, step-down converters. This family of devices offers design flexibility with a variety of user programmable functions, including soft-start, UVLO, operating frequency, voltage feed-forward, high-side current limit, and loop compensation. These devices are also synchronizable to an external supply.
The TPS40060 and TPS40061 are high‑voltage, wide‑input (10 V to 55 V) synchronous step‑down converters. They offer programmable functions such as soft‑start, UVLO, frequency, voltage feed‑forward, and current limit, and can be synchronized to an external supply.
The document includes ordering information, absolute maximum ratings, recommended operating conditions, electrical characteristics, terminal descriptions, a block diagram, application notes, a design example, and legal notices. It is intended for designers of networking, telecom, and base‑station equipment who need a flexible buck controller solution.
| Operating Input Voltage | 10 V to 55 V |
|---|---|
| Maximum Input Voltage (VIN) | 60 V |
| Maximum Switching Frequency | 1 MHz |
| Operating Temperature Range | –40 °C to 85 °C |
The controller operates from 10 V to 55 V input.
It is supplied in a 16‑Pin PowerPAD™ (PWP) package.
The device can be programmed for up to 1 MHz switching frequency.
Recommended operating temperature is –40 °C to 85 °C.
