Divar XF is a high-performance hybrid digital recorder from Bosch. It is ideal for medium to large-scale or growing systems and has four front-replaceable HD drives and extensive integration features. With real-time viewing, recording, and playback in genuine 4CIF resolution, the Divar XF captures all the details. Compared to traditional MPEG-4 systems, the Divar XF reduces bandwidth and storage needs by up to 30%.
The Divar XF Series Hybrid Digital Recorder is a high‑performance CCTV solution that combines analog and IP camera support, four front‑replaceable hard drives and optional RAID‑4 for reliable video storage. It offers real‑time H.264 recording at genuine 4CIF resolution while reducing bandwidth and storage needs.
This manual covers the recorder’s functions, ease‑of‑use features, interface options, technical specifications, installation notes, parts list, ordering information and available accessories. It also includes safety certifications, environmental limits and software licensing details.
| Power input | 100 to 240 VAC; 50/60 Hz |
|---|---|
| Power consumption | Max. 2.5 A (250 W) |
| Video resolution | 704x576 PAL, 704x480 NTSC (4CIF) |
| Video compression | H.264 |
| Hard drive capacity per disk | 250 GB, 500 GB, 750 GB or 1 TB |
| Maximum hard drives | Up to 4 front‑replaceable disks |
| RAID support | RAID‑4 (optional) |
| Dimensions (W×D×H) | 446 × 443 × 88 mm |
The recorder supports up to four front‑replaceable hard disks, which can be configured as a RAID‑4 array for extra reliability.
It records and plays back in genuine 4CIF resolution—704 × 576 PAL or 704 × 480 NTSC—using H.264 compression.
Yes, it can support up to eight optional H.264 IP cameras and up to 16 IP channels with the appropriate license.
The unit operates on 100‑240 VAC, 50/60 Hz and consumes up to 2.5 A (250 W) at maximum load.
