The D5070 Analog Device Programmer is a hand-held device that programs address settings on EEPROM-programmable analog devices. The D5070 consists of a base for detector head programming and a module programming adapter for relay module and point contact module programming.
The D5070 Analog Device Programmer is a compact, hand‑held device that programs address settings on EEPROM‑programmable analog devices such as detectors and modules. It includes a base for detector head programming and a module programming adapter for relay and point‑contact modules.
The manual provides installation and configuration notes, a compatibility list of programmable products, technical specifications, and a parts list. It also describes how detector heads mount and how modules connect to the programmer.
| Color | White |
|---|---|
| Dimensions (H x W x D) | 6.25 in. x 4 in. x 1.3 in. |
| Weight | 5.4 oz (154.2 g) |
| Voltage | 9 VDC |
| Battery life (address settings) | ≈8000 address settings per battery |
The D5070 can program EEPROM‑programmable analog devices, including analog point‑contact modules, heat detectors, photoelectric smoke detectors, duct smoke detectors, ionization smoke detectors, and various relay and module adapters.
It operates from a 9 VDC battery and can program roughly 8 000 address settings before the battery needs replacement.
The package contains the programmer, a 9 VDC battery, a four‑conductor jack, a two‑conductor jack, and a literature pack.
