This document is an instruction manual for a certain power tool. It provides information on operating and safety instructions for using the tool. The document highlights the safety precautions such as wearing safety glasses, protective gloves, sturdy shoes, and long pants, keeping children away from the machine, and not reaching into the feed opening or ejection chute during operation. Additionally, the document includes the model and technical specifications of the product.
This manual covers safety requirements, proper assembly, and general operating controls for the Bosch AXT 1600 HP and AXT 2000 HP garden waste shredders. It includes warnings, protective equipment recommendations, and instructions for safe handling of the machine and its accessories.
Detailed sections describe the tool specifications, noise and vibration data, initial operation steps, rotational direction control, overload protection, troubleshooting of common malfunctions, and maintenance procedures. Information on guarantees, service contacts, environmental recycling, and conformity declarations are also provided.
| Rated power | 1600 W (AXT 1600 HP), 2000 W (AXT 2000 HP) |
|---|---|
| No-load speed | 260 RPM |
| Maximum capacity | 100 kg/h (AXT 1600 HP), 115 kg/h (AXT 2000 HP) |
| Maximum branch diameter | 30 mm (AXT 1600 HP), 35 mm (AXT 2000 HP) |
| Weight | approx. 21 kg (AXT 1600 HP), approx. 22 kg (AXT 2000 HP) |
| Safety class | I / ⊕ |
Pull the mains plug and set the on/off switch to "O"; the motor will coast after switching off.
The A‑weighted sound pressure level is typically 84 dB(A).
Turn the rotational direction switch to the left position and switch the machine on to run the knives backwards, then return the switch to the right position after the blockage is cleared.
Use a supply voltage matching the tool identification plate (230 V or 220 V) and protect the circuit with a fuse of at least 10 A.
