This manual is intended for administrators and users of the AXIS 223M Network Camera, and is applicable for software release 4.47. It includes instructions for using and managing the AXIS 223M on your network. Previous experience of networking will be of use when using this product. Some knowledge of UNIX or Linux-based systems may also be beneficial, for developing shell scripts and applications. Later versions of this document will be posted to the Axis Website, as required. See also the product’s online help, available via the Web-based interface.
This manual covers the AXIS 223M network camera’s features, installation steps, and detailed configuration options. It explains how to access the camera via a web browser, set the root password, adjust focus and zoom, and manage video streams.
Technical specifications, power options, security settings, and troubleshooting guidance are included, along with a glossary of terms and regulatory approvals. The document also references the AXIS Camera Management tool and provides guidance for firmware upgrades and network integration.
| Image sensor | 1/2.7” Sony Wfine progressive scan RGB CCD |
|---|---|
| Lens | Computar HG2Z0414FC-MP-12, F1.4 varifocal 4.0–8.0 mm |
| Resolution (Motion JPEG) | 29 resolutions from 1600×1200 to 160×120 |
| Frame rate (Motion JPEG) | Up to 12 fps at 1600×900 (16:9) |
| Power | Power over Ethernet (IEEE 802.3af), Class 2 |
| Operating temperature | 0 – 50 °C (32 – 122 °F) |
The camera uses a 3.0 V CR2032 lithium battery to power the internal real‑time clock.
Yes, the AXIS 223M supports Power over Ethernet (IEEE 802.3af) and automatically negotiates the correct power level.
The camera supports Motion JPEG and MPEG‑4 Part 2 (ASP and SP) video compression.
