This manual is intended for administrators and users of the Axis P1343 Network Camera. It covers installation, network configuration, firmware updates, and basic operation, assuming some networking knowledge and familiarity with UNIX/Linux for advanced scripting.
The document includes a hardware overview with connector details, LED indicators, I/O functions, and specifications such as processor type, power options, dimensions, and storage. It also explains how to access the camera via web browsers, set the root password, and use optional features like PTZ, motion detection, and audio streaming.
| Processor | ARTPEC-3, 128 MB RAM, 128 MB Flash |
|---|---|
| Power | 8‑20 V DC or PoE (IEEE 802.3af, max 6.4 W, Class 2) |
| Casing | Metal (zinc) |
| Dimensions | 46 × 78 × 193 mm (1.8 × 3.1 × 7.6 in) |
| Weight | 0.6 kg (1.3 lb) |
| Network connector | RJ‑45 Ethernet, supports PoE |
| Audio input | 3.5 mm mono microphone/line‑in |
| Audio output | 3.5 mm line‑level output |
| Edge storage | SD/SDHC memory card slot (card not included) |
Use the RJ‑45 Ethernet connector with a shielded (STP) cable; the camera supports Power over Ethernet (PoE) and will work with a PoE‑enabled switch.
