The product is a Schottky diode, model SLD 10U, with a maximum peak power of 2200 watts and a maximum peak pulse power of 50,000 watts. It is used for protection of sensitive electronic devices in automotive systems.
The SLD Series diodes are designed for automotive applications to protect sensitive electronics such as sound systems, satellite navigation, climate control, engine management, stability control, and ABS. They are offered in unidirectional and bidirectional versions and meet UL 94V-0 flammability and RoHS standards.
Key specifications include a 2,200 W peak pulse power rating for a 100 µs/150 ms pulse, 50,000 W for an 8/20 µs pulse, a weight of 0.07 oz (2.1 g), and a P600 molded plastic case. Packaging options include tape and reel, and the devices feature axial leads suitable for MIL‑STD‑750 mounting.
| Peak pulse power (100 µs/150 ms) | 2,200 W |
|---|---|
| Peak pulse power (8/20 µs) | 50,000 W |
| Flammability classification | UL 94V-0 |
| RoHS compliance | Yes |
| Weight | 0.07 oz (2.1 g) |
| Case style | P600 |
| Maximum leakage current (Ir) – SLD10U | 10 µA |
Yes, the SLD series diodes are RoHS compliant.
They protect automotive electronics such as sound systems, satellite navigation, climate control, engine management, stability control, and ABS.
The diodes have a UL 94V-0 flammability classification.
