This document is the user manual for GA-H61M-DS2H motherboard, which describes the hardware installation, product specifications, CPU and memory installation methods, as well as the connection methods for expansion cards and interfaces.
This manual guides users through installing and configuring the GA-H61M-DS2H motherboard, covering CPU, memory, expansion cards, and peripheral connections. It also includes safety precautions, ESD handling, and warranty information.
The document contains a detailed table of contents, hardware layout diagrams, BIOS feature descriptions, driver installation steps, and regulatory statements. It serves both end‑users assembling a PC and technicians performing maintenance or upgrades.
| Chipset | Intel H61 Express |
|---|---|
| Memory Slots | 2 DDR3 DIMM sockets, up to 16 GB |
| Supported Memory Speed | DDR3 1333/1066/800 MHz |
| Onboard Graphics | 1 D‑Sub port, 1 HDMI port (max 1920×1200) |
| Audio Codec | Realtek/VIA HD audio, 2/4/5.1/7.1‑channel |
| LAN | Realtek/Atheros GbE 10/100/1000 Mbit |
| SATA Connectors | 4 × SATA 3 Gb/s |
| USB Ports | Up to 10 USB 2.0/1.1 ports (6 rear, 4 internal) |
| Form Factor | Micro ATX (24.4 cm × 17.4 cm) |
It provides up to 10 USB 2.0/1.1 ports – six on the back panel and four via internal headers.
It supports up to 16 GB of DDR3 system memory across two DIMM slots.
