The TLV5606 is a 10-bit voltage output digital-to-analog converter (DAC) with a flexible 4-wire serial interface. It can be used in a wide range of applications, including digital servo control loops, digital offset and gain adjustment, industrial process control, machine and motion control devices, and mass storage devices.
The TLV5606 is a 10‑bit voltage‑output digital‑to‑analog converter (DAC) that operates from a single 2.7 V to 5.5 V supply. It features a buffered high‑impedance reference input, programmable settling time, and an ultra‑low 10 nA power‑down current, making it suitable for industrial process control, machine and motion control, and mass‑storage devices.
Electrical specifications include a 10‑bit resolution, ±0.2 LSB differential nonlinearity, ±0.5 LSB integral nonlinearity, and a typical settling time of 9‑20 µs (full‑scale). The device is offered in an 8‑terminal SOIC package (DGK) and is available in tape‑and‑reel form.
| Supply voltage range | 2.7 V to 5.5 V |
|---|---|
| Resolution | 10 bits |
| Load resistance | 10 kΩ |
The TLV5606 operates from 2.7 V up to 5.5 V.
It provides a 10‑bit resolution.
