SN54ABT853, SN74ABT853 are 8-bit to 9-bit parity bus transceivers with high reliability, low power consumption, ESD protection, and high-drive outputs.
The SN54ABT853 and SN74ABT853 are 8‑bit to 9‑bit parity bus transceivers that generate and check parity bits during data transfers between two buses. They provide true data at their outputs and include a parity‑error (ERR) flag that can be latched, sampled, stored, or cleared via dedicated control inputs.
The devices operate over a wide temperature range, offer high‑drive outputs, robust ESD protection, and latch‑up performance. Detailed electrical characteristics, absolute maximum ratings, and timing requirements are provided for design and verification.
| Supply voltage range (VCC) | 4.5 V to 5.5 V |
|---|---|
| High‑level input voltage (VIH) | 2 V |
| Low‑level input voltage (VIL) | 0.8 V |
| Operating temperature range (SN54ABT853) | -55 °C to 125 °C |
| Operating temperature range (SN74ABT853) | -40 °C to 85 °C |
| ESD protection | Exceeds 2000 V per pin |
| Latch‑up performance | Exceeds 500 mA per pin |
Both devices operate with a supply voltage between 4.5 V and 5.5 V.
The SN54ABT853 is rated for -55 °C to 125 °C.
The transceiver includes ESD protection that exceeds 2000 V per pin.
