H77 Pro4/MVP is an ATX-form factor motherboard from ASRock that supports third-generation and second-generation Intel CoreTM i7 / i5 / i3 processors. This motherboard features a full solid capacitor design, support for Intel K-Series unlocked processors, Intel Turbo Boost 2.0 technology, Hyper-Threading Hyper-Threading technology, Intel Rapid Start technology, and Intel Smart Connect technology. Additionally, this motherboard supports DDR3 1600/1333/1066 non-ECC, un-buffered memory, PCI Express 3.0 x16 slot, PCI Express 2.0 x16 slot, PCI Express 2.0 x1 slot, and 3 x PCI slots, as well as multiple VGA output options: D-Sub, DVI-D, and HDMI.
This manual details the H77 Pro4/MVP motherboard’s hardware specifications, including CPU support, memory configurations, expansion slots, storage interfaces, audio and network components. It also lists the built‑in features such as Digi Power digital supply, Intel Quick Sync Video, and THX TruStudio audio.
The guide includes step‑by‑step installation procedures, BIOS configuration options, and descriptions of bundled software utilities like CyberLink MediaEspresso, MAGIX multimedia suite, and the ASRock Extreme Tuning Utility (AXTU). Troubleshooting tips and hardware monitoring features are also covered. This manual is written in Chinese.
| CPU Socket | LGA1155 |
|---|---|
| Supported CPUs | 3rd‑gen Intel Core i7/i5/i3 |
| Memory Type | DDR3 1600 |
| Maximum Memory | 32 GB |
| PCIe x1 Slots | 3 × PCI‑E x1 |
| SATA2 Ports | 4 |
| USB 3.0 Ports | 2 |
| USB 2.0 Ports | 6 |
| Audio Codec | Realtek ALC898 |
| Network Controller | Realtek RTL8111 |
It uses an LGA1155 socket compatible with third‑generation Intel Core i7, i5, and i3 processors.
The motherboard uses the Realtek ALC898 audio codec.
