This file is about the technical characteristics of R 15 products, including current carrying capacity, working current, ambient temperature, rated working voltage, rated impulse voltage, pollution degree, insulation resistance, material, surface treatment, terminal, mechanical working life, etc
This document provides the technical characteristics of the Harting R15 connector series. It lists the electrical ratings, material specifications, approvals and mechanical limits required for design and integration.
Key sections include electrical data (working voltage, current and impulse voltage), contact materials and plating, limiting temperatures, IP protection, and detailed part numbers for inserts, crimp terminals and housings. Accessories and mounting examples are also described.
| Working voltage | 250 V |
|---|---|
| Working current | 10 A |
| Rated impulse voltage | 4 kV |
| Pollution degree | 3 |
| Contact material | copper alloy |
| Contact plating (silver) | hard‑silver plated |
| Contact plating (gold) | hard‑gold plated |
| Limiting temperature (contacts) | -409 °C / +125 °C |
| Crimp terminal size range | 0.14 – 2.5 mm |
The R15 connector is rated for a working voltage of 250 V.
The rated impulse voltage is 4 kV.
Contacts are made of copper alloy and are available with hard‑silver or hard‑gold plating.
