The EL5172 and EL5372 are single and triple high bandwidth amplifiers designed to extract the difference signal from noisy environments. They are primarily targeted for applications such as receiving signals from twisted-pair lines or any application where common mode noise injection is likely to occur. The EL5172 and EL5372 are stable for a gain of one and requires two external resistors to set the voltage gain. The output common mode level is set by the reference pin (VREF), which has a -3dB bandwidth of over 120MHz. Generally, this pin is grounded but it can be tied to any voltage reference. The output can deliver a maximum of ±60mA and is short circuit protected to withstand a temporary overload condition. The EL5172 is available in the 8-pin SO and 8-pin MSOP packages and the EL5372 in a 24-pin QSOP package. Both are specified for operation over the full -40°C to +85°C temperature range.
The EL5172 and EL5372 are high‑bandwidth differential line receivers designed for extracting the difference signal from noisy environments such as twisted‑pair lines. They operate over a temperature range of –40 °C to +85 °C and can deliver up to +60 mA of output current.
Key features include a 250 MHz 3 dB bandwidth, 800 V/µs slew rate, and low power consumption (5‑6 mA per channel). The devices are offered in 8‑pin SO, 8‑pin MSOP (EL5172) and 24‑pin QSOP (EL5372) packages, with detailed pin descriptions and performance curves provided.
| Differential input range | +2.3 V |
|---|---|
| 3 dB bandwidth | 250 MHz |
| Slew rate | 800 V/µs |
| Maximum output current | 60 mA |
| Operating temperature range | -40 °C to +85 °C |
| EL5172 package options | 8‑pin SO, 8‑pin MSOP |
The EL5172 is offered in 8‑pin SO and 8‑pin MSOP packages.
They operate from –40 °C to +85 °C.
