The LP2982 is a 50 mA, fixed-output voltage regulator designed to provide ultra low dropout and lower noise in battery powered applications. It delivers unequaled performance in all specifications critical to battery-powered designs.
The LP2982 micropower regulator provides a fixed 50 mA output with ultra‑low dropout voltage and very low ground‑pin current, making it suitable for battery‑powered designs. It is offered in SOT‑23 and micro‑SMD (5‑bump) packages and requires only minimal external components.
The document includes detailed electrical characteristics, absolute maximum ratings, typical performance curves, ordering information for various voltage grades, and physical dimensions. It also contains application hints, package markings, and compliance notes.
| Output current | 50 mA (fixed) |
|---|---|
| Typical dropout voltage | 120 mV @ 50 mA load |
| Ground pin current | 375 pA @ 50 mA load |
| Output voltage accuracy | ±1.0 % (A‑grade) |
| Supply voltage range (operating) | 2.1 V to 16 V |
| Operating temperature range | -40 °C to +125 °C |
The typical dropout voltage is 120 mV when the device supplies 50 mA.
The device can deliver a typical continuous output of 50 mA and a peak output current of about 150 mA.
