The LMH6733 is a triple, wideband, operational amplifier designed specifically for use where high speed and low power are required. Input voltage range and output voltage swing are optimized for operation on supplies as low as 3V and up to ±6V. Benefiting from National’s current feedback architecture, the LMH6733 offers a gain range of ±1 to ±10 while providing stable operation without external compensation, even at unity gain. These amplifiers provide 650 MHz small signal bandwidth at a gain of 2 V/V , a low 2.1 nV/ input referred noise and only consume 5.5 mA (per amplifier) from a single 5V supply.
The LMH6733 is a triple, wideband operational amplifier designed for high‑speed, low‑power applications. It operates from single supplies as low as 3 V up to 12 V, or split supplies from +1.5 V to +6 V, and provides a gain range of +1 to +10 without external compensation. Key specifications include a 1.0 GHz –3 dB bandwidth, 1900 V/µs slew rate, low input offset voltage (0.4‑2.0 mV), and a typical supply current of about 16.7 mA per amplifier. The device is offered in a 16‑Pin SSOP package and is suited for applications such as HDTV component video drivers, high‑resolution projectors, flash A/D drivers, and radar/communication receivers.
| Supply range (single) | 3 V to 12 V |
|---|---|
| Supply range (split) | +1.5 V to +6 V |
| Bandwidth (‑3 dB) | 1.0 GHz |
| Input Offset Voltage | 0.4 mV – 2.0 mV |
| Linear Output Current | 70 mA |
| Package | 16‑Pin SSOP |
It can operate from 3 V to 12 V on a single supply, or from +1.5 V to +6 V on a split supply.
The device provides a 1.0 GHz –3 dB bandwidth at unity gain.
The LMH6733 is offered in a 16‑Pin SSOP package.
