This document is the datasheet for DS2792, which introduces the functions and features of the product and its application scenarios
The DS2792 is a programmable fuel‑gauge IC that integrates a 16‑bit MAXQ20 microcontroller, EEPROM, RAM, and analog measurement peripherals for Li‑ion and NiMH battery packs. It provides current, voltage, and temperature monitoring and communicates via a 19.2 kbps UART interface.
Key features include a supply voltage range of 2.5 V‑10 V, low‑power operation (CPU mode 1.5 mA, sleep mode ~25 µA), 4 k‑word EEPROM program memory, 64 words data EEPROM, and a 28‑pin TDFN package. The device supports JTAG debugging and offers extensive pin‑out and electrical specifications for designers.
| Supply Voltage (Vop) | 2.5 V to 10 V |
|---|---|
| Operating Temperature Range | 40 °C to 85 °C |
| CPU Mode Current | 1.5 mA |
| UART Maximum Data Rate | 19200 bps |
| Program Memory (EEPROM) | 4 k Words |
| Data EEPROM Memory | 64 Words |
| Package Type | TDFN‑28 (28‑pin) |
| Current Measurement Resolution | 15.625 µV/RSNS |
The device operates from 2.5 V to 10 V supply voltage.
The UART interface can transmit up to 19.2 kbps (maximum 19200 bps).
The DS2792 is supplied in a 28‑pin TDFN package.
It is rated for operation from 40 °C to 85 °C.
