AD5725 is a 12-bit parallel input single/dual-polarity voltage output DAC, suitable for industrial automation, closed-loop servo control, process control, automotive test and measurement, programmable logic controllers and other applications
The AD5725 is a quad, 12‑bit, parallel‑input, voltage‑output digital‑to‑analog converter. It supports both unipolar and bipolar operation with supply voltages from +5 V to +15 V and offers a guaranteed monotonic response, ±0.5 LSB integral nonlinearity and a typical 10 µs settling time.
The device is supplied in a 28‑lead SSOP package, consumes less than 270 mW at a +15 V supply, and operates over an industrial temperature range of –40 °C to +85 °C. Detailed specifications include resolution, accuracy, bandwidth, timing, and absolute maximum ratings.
| Resolution | 12 Bits |
|---|---|
| Relative Accuracy (INL) | +0.5 LSB max (B grade) |
| Differential Nonlinearity (DNL) | +1 LSB max |
| Power Dissipation | 270 mW max |
| Output Current | 45 mA max |
| Large Signal Bandwidth | 160 kHz typ |
| Operating Temperature Range | –40 °C to +85 °C |
| Supply Voltage Range | +5 V to +15 V |
The AD5725 provides a 12‑bit resolution.
The device dissipates up to 270 mW at a +15 V supply.
It operates from –40 °C to +85 °C.
The typical large‑signal bandwidth is 160 kHz.
