The LP2980 is a 50 mA, fixed-output voltage regulator designed specifically to meet the requirements of battery-powered applications. The LP2980 delivers unequaled performance in all specifications critical to battery-powered designs.
The LP2980 is a fixed‑output, 50 mA low‑dropout regulator designed for battery‑powered applications. It uses an optimized VIP™ process to achieve a typical dropout voltage of 120 mV at 50 mA load and a ground‑pin current of 375 pA.
The device is offered in 5.0 V, 3.3 V and 3.0 V versions, packaged in SOT‑23 or micro‑SMD formats, and requires only 1 µF of external output capacitance for stable operation. It operates from 2.1 V to 16 V input and includes over‑temperature and over‑current protection.
| Dropout Voltage | Typical 120 mV @ 50 mA load |
|---|---|
| Output Voltage Accuracy | 0.5 % tolerance (A‑grade) |
| Maximum Output Current | 50 mA (guaranteed) |
| Ground Pin Current | Typically 375 pA @ 50 mA load |
| Sleep Mode Quiescent Current | < 1 µA when ON/OFF pin low |
| Input Supply Voltage (Operating) | 2.1 V to 16 V |
| Recommended Output Capacitance | Minimum 1 µF |
| Operating Temperature Range | -40 °C to +125 °C (junction) |
The typical dropout voltage is 120 mV at a 50 mA load.
The LP2980 guarantees a maximum output current of 50 mA.
A minimum of 1 µF external capacitance is required for stability.
It operates from –40 °C to +125 °C junction temperature.
