CC2500 is a low cost true single chip 2.4 GHz transceiver designed for very low power wireless applications. Applications include 2400-2483.5 MHz ISM/SRD band systems, consumer electronics, wireless game controllers, wireless audio and wireless keyboard and mouse.
The CC2500 is a single‑chip, low‑cost, low‑power 2.4 GHz RF transceiver designed for ISM/SRD band applications such as wireless game controllers, audio, keyboards and mice. It integrates a configurable baseband modem and supports various modulation formats with data rates up to 500 kbps.
Key features include a small QLP 4×4 mm 20‑pin package, on‑chip frequency synthesizer, programmable output power, wake‑on‑radio, and extensive packet‑handling hardware. The data sheet lists absolute maximum ratings, operating conditions, electrical specifications, pin configuration and configuration software details.
| Frequency range | 2400‑2483.5 MHz |
|---|---|
| Maximum data rate | 500 kbps |
| Supply voltage | 1.8 V – 3.6 V |
| Typical receive current (250 kbps) | 13.3 mA |
| Package size | QLP 4×4 mm, 20 pins |
| Receiver sensitivity | -104 dBm |
It operates in the 2400‑2483.5 MHz ISM/SRD band.
The transceiver supports a programmable data rate up to 500 kbps.
The device operates with a supply voltage between 1.8 V and 3.6 V.
Typical receiver sensitivity is –104 dBm (can improve to –106 dBm with settings).
