The XTR117 is a precision current output converter designed to transmit analog 4-20mA signals over an industry-standard current loop. It provides accurate current scaling and output current limit functions.
The XTR117 is a precision current‑output converter that transmits analog 4‑20 mA signals over an industry‑standard current loop. It features a low quiescent current of 130 µA, a wide supply voltage range of 7.5 V to 40 V, and an on‑chip 5 V regulator that can power external circuitry. The device provides accurate current scaling, output‑current limiting, and a current‑return pin for monitoring external load.
Typical applications include two‑wire industrial process control, test systems, and smart sensor designs. The part is offered in MSOP‑8 and DFN‑8 packages with detailed ordering information and packaging guidelines for reliable PCB assembly.
| Quiescent Current | 130 µA |
|---|---|
| Supply Voltage Range | 7.5 V to 40 V |
| Linear Output Current Range | 0.20 mA to 25 mA |
| Over‑Scale Current Limit | 32 mA |
| Operating Temperature Range | -40 °C to +125 °C |
The device has a low quiescent current of 130 µA.
It operates with a supply voltage from 7.5 V up to 40 V.
It provides a linear output range of 0.20 mA to 25 mA and an absolute over‑scale limit of 32 mA.
The device is specified for operation from –40 °C to +125 °C.
