This manual introduces the features and characteristics of the DSL-G604T Generation II ADSL2+ Wireless Modem Router, and provides steps on how to configure the router.
The DSL‑G604T Generation II is an ADSL2+ modem‑router with built‑in 802.11g wireless. It connects a private Ethernet LAN and wireless devices to the Internet via an ADSL line and includes standard Ethernet ports, a wireless access point and a range of routing features.
This user guide covers hardware installation, the setup wizard for PPPoE/PPPoA connections, wireless security settings (WEP, WPA, WPA2), advanced functions such as NAT, DHCP, port forwarding, QoS and SNMP, as well as troubleshooting tools, firmware updates and technical specifications.
| Data Transfer Rate | Downstream up to 24 Mbps, upstream up to 1 Mbps |
|---|---|
| LAN Interface | RJ‑45 port for 10/100BASE‑T Ethernet |
| WAN Interface | RJ‑11 connector for ADSL telephone line |
The default LAN IP address is 10.1.1.1, which can be entered in a web browser to reach the router’s GUI.
It supports 64‑bit and 128‑bit WEP, WPA and WPA2 encryption.
