VEMI85AA-HGK is an 8-channel EMI filter produced by Vishay Semiconductors. It uses an ultra-compact LLP3313-17L package with a package profile of only 0.6mm. The product features low leakage current, line resistance of 100Ω, typical cutoff frequency of 100MHz, and ESD protection.
The VEMI85AA-HGK is an ultra‑compact 8‑channel EMI filter designed for signal or data lines. It provides bidirectional ESD protection per IEC 61000‑4‑2 (±30 kV) and features a low‑profile LLP3313‑17L package only 0.6 mm high. All channels share a common ground pin and can be used interchangeably as inputs or outputs.
Key electrical characteristics include a line resistance of 100 Ω, typical cutoff frequency of 100 MHz, and clamping voltages of 7 V (positive) and –1 V (negative) under IEC 61000‑4‑5 test conditions. The device complies with RoHS, WEEE and offers a maximum operating temperature range of –40 °C to +125 °C. This manual is written in Chinese.
| Package height | 0.6 mm |
|---|---|
| Line resistance (RS) | 100 Ω |
| Typical cutoff frequency (f3dB) | 100 MHz |
| Number of protected channels | 8 |
The device uses an ultra‑compact LLP3313‑17L package with a height of 0.6 mm.
It provides protection for eight independent channels.
Each channel has a line resistance of 100 Ω.
It meets IEC 61000‑4‑2 with ±30 kV contact and air discharge capability.
