This document is the user manual for the evaluation board of Freescale Flexis QE128 microcontrollers. The manual describes the features and characteristics of the product, including the 80-pin LQFP package, the intended use and environment of the product, and matters related to safety and electromagnetic compatibility.
The EVBQE128 Evaluation Board is designed for evaluating, demonstrating, and debugging Freescale Flexis QE128 microcontrollers. It can operate as a standalone device or be controlled by a host PC via the built‑in microDART USB interface. The board includes an 80‑pin LQFP socket, power supply options, RS‑232 ports, and various I/O components.
The manual provides detailed hardware descriptions, software installation steps for CodeWarrior Development Studio, jumper and connector settings, and troubleshooting guidance for USB driver and communication issues.
| Power supply input | 12 V DC barrel connector (2.1 mm) |
|---|---|
| Microcontroller socket | 80‑pin LQFP socket for MC9S08QE128 or MCF51QE128 |
| RS‑232 ports | Two RS‑232 connectors with enable jumper |
| User LEDs | Ten user LEDs |
The board can be powered either from the USB bus or from the 12 V DC barrel connector, selected by the POWER SEL jumper.
