The MAX13481E/MAX13482E/MAX13483E ±15kV ESD-protected USB-compliant transceivers interface low-voltage ASICs with USB devices. The transceivers fully comply to USB 2.0 when operating at full-speed (12Mbps). The transceivers also operate with VL as low as 1.6V, ensuring compatibility with low-voltage ASICs. The MAX13481E/MAX13482E/MAX13483E feature a logic-selectable suspend mode that reduces current consumption. Integrated ±15kV ESD circuitry protects D+ and D- bus connections. The MAX13481E/MAX13482E/MAX13483E operate over the extended -40°C to +85°C temperature range and are available in a 16-pin (3mm x 3mm) thin QFN package. Applications: Cell Phones, PDAs, Digital Still Cameras
The MAX13481E, MAX13482E, and MAX13483E are ±15 kV ESD‑protected USB‑compliant transceivers that interface low‑voltage ASICs with USB devices. They operate at full‑speed (12 Mbps) from a supply voltage as low as 1.6 V and include logic‑selectable suspend mode to reduce power consumption.
The devices are supplied in a 16‑pin 3 mm × 3 mm thin‑QFN package and feature built‑in voltage regulators, pull‑up resistors, and bus‑detect outputs. Detailed electrical characteristics, timing parameters, pin descriptions, and recommended external components are provided for designers.
