The MAX14780E is a half-duplex serial communication transceiver from MAXIM with ±30kV ESD protection, 1/8 unit load receiver input impedance, and error-free data transmission at a data rate of 500kbps.
The MAX14780E is a +5 V, +30 kV ESD‑protected RS‑485/RS‑422 transceiver with fail‑safe receiver, hot‑swap capability, and reduced slew‑rate drivers for error‑free data transmission up to 500 kbps. It supports half‑duplex communication, draws low supply current, and allows up to 256 transceivers on a single bus.
The datasheet details absolute maximum ratings, DC electrical characteristics, driver and receiver switching timings, and typical application circuits. Package options include 8‑pin SO and PDIP, and the document lists ordering information, thermal‑shutdown thresholds, and revision history.
| Supply Voltage (VCC) | 0.3 V to +6 V |
|---|---|
| Supply Current (no load) | 1.2 mA |
| Maximum Data Rate | 500 kbps |
| Package Types | 8‑pin SO and PDIP |
| Driver Output Current | 250 mA |
| Thermal‑Shutdown Threshold | 175 °C |
The MAX14780E supports a maximum data rate of 500 kbps.
Up to 256 MAX14780E transceivers can be placed on a single bus.
The device is offered in 8‑pin SO and PDIP packages.
The supply current is approximately 1.2 mA with no load.
