This document introduces Pulse's RF chip inductor series products, which provide high-quality filtering in mobile phones, wireless applications, digital cameras, disk drives, and audio equipment. These inductors are also used in multi-purpose RF modules for telecom, automotive, and consumer electronic applications. They use wirewound technology with ceramic or ferrite cores in industry standard sizes and footprints. From the ultra-small, low-profile 0402 series to the 1812 series reaching 1 mH inductance value. Pulse is able to meet all your needs in a wide range of applications. Pulse's RF chip inductor series is matched in performance to the industry competition with full compatibility and operating frequency ranges.
Pulse manufactures miniature wire‑wound RF chip inductors for use in mobile phones, wireless devices, digital cameras, disk drives, audio equipment, telecom, automotive and other consumer‑electronics applications. The inductors are offered in industry‑standard surface‑mount sizes and footprints.
The catalog lists multiple series (0402, 0603, 0805, 1008, 1206) with detailed parameters such as inductance, Q factor, self‑resonant frequency, tolerance and current rating, and includes ordering information for optional tolerances and RoHS‑compliant parts.
| Standard tolerance | 10% |
|---|---|
| Compliance | RoHS compliant |
| Technology | Wirewound with ceramic or ferrite cores |
Refer to the Part Number Ordering Guide on the last page of the catalog for ordering parts with optional tolerances.
