The ANSMANN 8194047 is a compact AC/DC plug‑in power supply designed for medical equipment. It accepts a wide input voltage range and provides a regulated low‑voltage DC output with built‑in protection features.
The device complies with medical safety standards (CE, EN 60601) and includes primary fuse protection, secondary electrical protection, and IP20 enclosure rating. Detailed electrical parameters, operating limits, and packaging information are listed below. This manual is written in German.
| Input voltage | 100‑240 V AC, 50/60 Hz |
|---|---|
| Output voltage (nominal) | max 6.3 V DC |
| Output current (nominal) | 800 mA |
| Power consumption (idle) | < 0.3 W |
| Ripple voltage | < 300 mV |
| Primary protection | Gloss fuse TR 5 A |
| Approvals | CE, BUREAU VERITAS, EN 60601 |
| Applicable standards | IEC/EN 61558, IEC/EN 60601‑1, IEC/EN 60601‑1‑2 |
It operates from 100 V to 240 V AC at 50 Hz or 60 Hz.
The nominal output current is 800 mA.
It carries CE marking, BUREAU VERITAS certification and conforms to EN 60601.
The maximum output voltage is 6.3 V DC.
