The MAX4434-MAX4437 series of precision op amps feature wide bandwidth, 16-bit accurate settling time 23ns and low noise/low distortion characteristics.
The MAX4434‑MAX4437 family are single‑supply voltage‑feedback operational amplifiers offering 150 MHz bandwidth, 16‑bit settling in 23 ns, and ultra‑low distortion. They are optimized for high‑speed 14‑ and 16‑bit ADC front‑ends and provide up to 65 mA output drive.
The devices are available in compact 5‑pin SOT‑23 (MAX4434/5) and 8‑pin µMAX (MAX4436/7) packages. Detailed electrical characteristics, pin configurations, and layout recommendations are included to aid PCB design and ensure stable operation.
| Supply current per amplifier | 15 mA |
|---|---|
| Open‑loop gain | 115 dB |
| Voltage noise density | 2.2 nV/√Hz |
| Spurious‑free dynamic range (SFDR) at 1 MHz | 97 dB |
| Small‑signal -3 dB bandwidth | 150 MHz |
| Output drive capability | 65 mA |
| Slew rate (MAX4435/7) | 388 V/µs |
| Quiescent current (per amplifier) | 15‑18 mA |
Each amplifier draws about 15 mA of supply current.
The small‑signal -3 dB bandwidth is 150 MHz for all devices.
MAX4434 and MAX4435 are offered in 5‑pin SOT‑23 packages, while MAX4436 and MAX4437 use 8‑pin µMAX packages.
Typical quiescent current is 15 mA, rising to 18 mA at maximum temperature.
