MAX9060 series products are a kind of miniature single comparators produced by Texas Instruments. They are very suitable for a wide range of portable electronic applications such as cell phones, media players and notebooks which have extremely tight board space and power constraints. The series products provide ultra-miniature 4-bump UCSP package with a 1mm x 1mm footprint (as small as two 0402 resistors); and also provide 5-pin SOT23 package. The series products feature an input voltage range of -0.3V to +5.5V independent of supply voltage. These devices maintain high impedance at the inputs even when powered down (VCC or VREF = 0V). They also feature internal filtering to provide high RF immunity. MAX9060 and MAX9061 have open-drain outputs and draw quiescent supply current from a user-supplied reference voltage, VREF, between 0.9V and 5.5V. These devices consume only 100nA (max) supply current and operate over the extended -40°C to +85°C temperature range. MAX9062, MAX9063 and MAX9064 are single com- parators with an internal 0.2V reference. These devices feature either a push-pull or an open-drain output. They consume only 700nA (max) supply current. The MAX9062, MAX9063, and MAX9064 operate down to VCC = 1V over the extended -40°C to +85°C temperature range.
The MAX9060‑MAX9064 family are ultra‑small, low‑power single comparators offered in a 4‑bump UCSP package (1 mm × 1 mm) and a 5‑pin SOT23 package. They are designed for space‑constrained, battery‑operated devices such as cell phones, media players, notebooks, and medical gadgets.
Key features include an input voltage range of –0.3 V to +5.5 V, ultra‑low supply current (as low as 100 nA), extended temperature operation from –40 °C to +85 °C, and internal filtering for high RF immunity. The family provides both open‑drain and push‑pull output options and includes an internal 0.2 V reference for certain models.
| Input Voltage Range | -0.3 V to +5.5 V |
|---|---|
| Supply Current (MAX9060/9061) | 100 nA max |
| Operating Temperature Range | -40 °C to +85 °C |
The devices accept input voltages from –0.3 V up to +5.5 V.
They consume as little as 100 nA (maximum) supply current.
They are rated for operation from –40 °C to +85 °C.
