This document provides technical data and a user guide for the Bendix/King® Autopilot System KAP 140. It includes export license eligibility, copyright notice, and revision history and instructions. The KAP 140 is a flight autopilot system, and this document describes its features and characteristics.
This guide introduces the KAP 140 autopilot system, covering both single‑axis and two‑axis configurations, as well as the two‑axis with altitude pre‑select option. It describes system integration, power application, and pre‑flight tests, and explains the various operating modes such as Wing Leveler, Heading Select, Navigation, Approach, and Back Course.
Detailed sections provide step‑by‑step procedures for takeoff, climb, GPS capture, altitude hold, vertical speed, and handling abnormal circumstances. Revision history and part numbers are listed for reference, and contact information for Honeywell Aerospace is included at the end of the document.
The part number is 006-18034-0000.
Revision 3, November 2005 changed CW to CCW on page 116.
Honeywell International Inc. holds the copyright.
