This document is the user manual for the P5KPL-AM SE ii E4236 First Edition V1 motherboard by ASUSTeK Computer INC. It describes the features and characteristics of the product.
This manual covers the ASUS P5KPL-AM SE motherboard, a uATX form‑factor board with an LGA775 socket, Intel G31 northbridge, and a range of integrated features. It includes safety guidelines, hardware installation steps, and detailed BIOS configuration instructions.
The document also lists the technical specifications such as supported CPUs, memory types, expansion slots, storage interfaces, networking, audio, USB ports, and power connectors, plus tools for BIOS updates and system recovery. This manual is written in Chinese.
| CPU socket | LGA775 |
|---|---|
| Chipset | Northbridge Intel G31, Southbridge Intel ICH7 |
| Expansion slots | 1 × PCI‑Express x16, 1 × PCI‑Express x1, 1 × PCI |
| Integrated graphics | Intel GMA3100, max resolution 2048 × 1536 |
| Storage interfaces | 1 × UltraDMA 100/66/33 HDD, 2 × SATA 3 Gb/s ports |
| LAN | Realtek RTL8102EL, 10/100 Mbps |
| Audio | 6‑channel ALC662 high‑definition codec |
| USB ports | 8 × USB 2.0 (4 mid‑board, 4 back‑panel) |
| Form factor | uATX 9.6 in × 7.2 in (24.5 cm × 18.3 cm) |
Erase the CMOS Real Time Clock (RTC) RAM as described in the Jumpers section to clear the BIOS password.
