QuantuMike is the new generation micrometer from Mitutoyo, a world leading manufacturer of precision measurement equipment. It features the most advanced manufacturing and processing technologies, providing users with a better measuring experience with higher speed, quality and stability
The QuantuMike is a next‑generation coolant‑proof micrometer that uses a coarse 2 mm thread lead per thimble revolution, delivering up to 60 % faster positioning and 35 % shorter measuring times compared with conventional models. Its patented ratchet thimble mechanism and function‑lock feature provide repeatable measurements and prevent accidental origin shifts.
The instrument is rated IP65 for dust and water resistance, operates on a single SR44 silver‑oxide battery with an estimated three‑year life, and offers a data‑output function on selected models for integration with statistical process control systems. Optional accessories include USB conversion tools, connection cables, and colored speeder sleeves.
| Accuracy | +1 µm / .00005 in |
|---|---|
| Protection level | IP65 (IEC60529) |
| Measuring force | 7‑12 N |
| Power supply | SR44 silver‑oxide battery (1 piece) |
| Battery life | Approx. 3 years under normal conditions |
| Data output function | Available on models 293‑140, 293‑141, 293‑180, 293‑181 |
It is rated IP65, providing sealed protection against dust and water jets.
The SR44 battery lasts approximately three years under normal conditions.
Models 293‑140, 293‑141, 293‑180 and 293‑181 are equipped with a data‑output port.
