The Graphics PICtail™ Plus Daughter Board 2 is a demonstration board for evaluating Microchip Technology’s graphic LCD display solution and Graphics Library for 16 and 32-bit microcontrollers.
The Graphics PICtail™ Plus Daughter Board 2 is a demonstration board for evaluating Microchip Technology's graphic LCD display solution and Graphics Library for 16 and 32‑bit microcontrollers. It expands the Explorer 16 development board.
The guide describes the board's QVGA LCD module, built‑in SSD1906 graphics controller, flash memory, buzzer, and jumper configurations, and explains how to connect and program the board using the Microchip Graphics Library.
| LCD resolution | QVGA (320x240) |
|---|---|
| Graphics controller | Solomon Systech SSD1906 |
| Flash memory | 4 Mbit (6 128) |
| Touch screen type | Resistive |
An Explorer 16 development board is required.
Jumper JP3 controls the sound buzzer; when the jumper is open, the buzzer is disabled.
Visit the Microchip website at www.microchip.com/graphics for the latest documentation, schematics, source code, and examples.
