The DP83848K PHYTER® Mini LS is an industrial temperature single port 10/100 Ethernet transceiver. It features low-power 3.3V, 0.18µm CMOS technology, auto-MDIX for 10/100 Mb/s, energy detection mode, RMII and MII interfaces, IEEE 802.3u auto-negotiation and parallel detection, etc.
The DP83848K PHYTER® Mini LS is a single‑port 10/100 Mbps Ethernet transceiver designed for space‑sensitive industrial applications. It offers superior performance beyond 137 m of Cat‑V cable, Auto‑MDIX, and robust ESD protection greater than 4 kV HBM.
The device is supplied in a compact 6 mm × 6 mm LLP 40‑pin package, supports both MII and RMII interfaces, and provides two configurable LEDs for link and speed status. Detailed pin descriptions, register maps, and timing specifications are included for hardware and software integration.
| Package | 6 mm × 6 mm LLP 40‑pin |
|---|---|
| Supply Voltage | Low‑power 3.3 V CMOS |
| ESD Protection | > 4 kV Human Body Model |
| Auto‑MDIX | Supported for 10/100 Mb/s |
| LED Indicators | Two LEDs (Link and Speed) |
It uses a 6 mm × 6 mm LLP 40‑pin package.
The device provides ESD protection greater than 4 kV Human Body Model.
Yes, it supports Auto‑MDIX for 10/100 Mb/s operation.
Two LEDs are provided: one indicates link status and the other indicates speed.
