The Fluke 117 Electrician's Multimeter features non-contact voltage detection, automatic ac/dc voltage selection, LoZ to prevent false readings, and other characteristics. It also includes a large LED backlight, true-rms for accurate measurements, and the ability to measure 20A current. It is ideal for commercial buildings, hospitals, and schools.
The Fluke 117 is a compact true‑RMS multimeter designed for commercial and industrial environments. It offers non‑contact voltage detection (VoltAlert™), automatic AC/DC voltage selection, LoZ ghost‑voltage protection, and a large white LED backlight for low‑light work.
Technical data include measurement ranges for voltage, current, resistance, capacitance, frequency and diode testing, along with accuracy specifications, safety rating (CAT III 600 V), battery type, and ordering information. The manual also lists environmental limits and surge protection details.
| DC voltage range | 6.000 V |
|---|---|
| AC voltage range (true‑RMS) | 600.0 V |
| Maximum current measurement | 20 A (30 s momentary; 10 A continuous) |
| Battery type | 9 V Alkaline (NEDA 1604A/ IEC 6LR61) |
| Safety rating | CAT III 600 V |
| True‑RMS capability | Yes |
The Fluke 117 is rated CAT III 600 V for safety.
It uses a 9‑volt Alkaline battery (NEDA 1604A/ IEC 6LR61).
It can measure up to 20 A (30 seconds momentary, 10 A continuous).
Yes, it includes VoltAlert™ technology for non‑contact voltage detection.
