The Fluke 353/355 Clamp Meters are ideal for measuring high currents up to 2000 A with accurate peak measurements. They also feature a wide measurement range, as well as CAT IV 600 V, CAT III 1000 V ratings for added protection when measuring high-powered circuits.
The Fluke 350 Series includes the 353 and 355 AC/DC clamp meters, offering True‑RMS measurements, motor start‑up current, and voltage/resistance functions. Both models provide a rugged design with CAT IV 600 V and CAT III 1000 V ratings for high‑current industrial use.
Key specifications include a current range up to 2000 A (1400 A AC rms), voltage up to 1000 V DC, resistance up to 400 Ω, and a jaw opening of 58 mm. The meters run on 6 V AA batteries with an estimated 100‑hour battery life and feature a backlit display, continuity beeper, and min/max/average readings.
| Maximum current range | 0‑2000 A (1400 A AC rms) |
|---|---|
| Voltage range | 0‑1000 V DC |
| Resistance range | 0‑400 Ω |
| Continuity beeper threshold | < 30 Ω |
| Power supply | 6 V‑1.5 V AA batteries |
| Battery life | 100 hours |
| Size (HxWxD) | 300 mm × 98 mm × 52 mm |
| Jaw opening | 58 mm |
| Weight | 0.814 kg |
It can measure up to 2000 A, with a 1400 A AC rms capability.
The Fluke 353 comes with a C43 Soft Meter Case, six AA batteries, and the user manual.
The battery life is rated for about 100 hours of use.
