APDS-9303 is a miniature digital ambient light photo sensor from APD company. It converts light intensity to digital signal output with direct SMBus interface. APDS-9303 adopts a precise photoelectric sensing technology, which features high light responsivity and sensitivity, and can detect extremely weak light. APDS-9303 also has many other advantages, including low power consumption, compact size, and fast response time. APDS-9303 can be widely used in various ambient light sensing applications, such as mobile phones, tablets, laptops, etc.
The APDS-9303 is a miniature ambient‑light photo sensor that converts light intensity to a 16‑bit digital output via an SMBus interface. It contains a broadband (visible + IR) photodiode and a dedicated infrared photodiode, each feeding an integrating ADC.
The device is offered in a 6‑pin ChipLED package (2.60 mm × 2.20 mm × 0.55 mm) and supports programmable gain, integration time, and interrupt thresholds. Typical applications include back‑light control for mobile devices, notebooks, tablets, LCD monitors, automotive instrument clusters, and electronic signage.
| Supply voltage (recommended) | 2.7 V – 3.6 V (typical 3.3 V) |
|---|---|
| Maximum supply voltage | 3.8 V |
| Digital output voltage range | -0.5 V to 3.8 V |
| Storage temperature range | -40 °C to 85 °C |
| Supply current (active mode) | 0.24 mA – 0.6 mA |
| Oscillator frequency | 690 kHz – 780 kHz (typical 735 kHz) |
| Full‑scale ADC count | 65535 counts |
| Package dimensions | Height 0.55 mm, Length 2.60 mm, Width 2.20 mm |
The recommended supply voltage is 3.3 V, with an allowable range from 2.7 V to 3.6 V.
