Q Series 60.132 Watt DC-DC Converters, input voltage ranges up to 168 V DC, 1 or 2 isolated outputs, 3.3.48 V DC, 3 kV AC I/O electric strengh test voltage
The Q Series from Power-One offers compact, low‑inrush, hot‑swappable DC‑DC converters with input voltages up to 168 V DC and one or two isolated outputs ranging from 3.3 V to 48 VDC. Power ratings span 60 W to 132 W and efficiency can reach up to 88 % while operating in ambient temperatures from –40 °C to 71 °C.
This manual includes selection charts, safety approvals (EN 60950, UL 1950, CSA C22.2 No. 950), environmental specifications, pin allocations, and accessory options. Protection features such as input reverse‑polarity fuses, over‑/undervoltage lockout, and overload protection are described, along with mechanical data and mounting guidelines.
| Input voltage range | up to 168 V DC |
|---|---|
| Output voltage range | 3.3‑48 VDC |
| Power rating | 60‑132 W |
| Inrush current (typical) | 40 A |
| Operating ambient temperature | -40 °C to 71 °C |
| Protection degree | IP20/30 |
| Safety approvals | EN 60950, UL 1950, CSA C22.2 No. 950 |
The converters accept input voltages up to 168 V DC.
It is approved to EN 60950, UL 1950 and CSA C22.2 No. 950 standards.
The unit operates from –40 °C to 71 °C.
