The FTDI DB9‑USB‑RS232 module provides a drop‑in replacement for legacy DB9 RS232 connectors, converting the serial signals to USB using the FT232R bridge IC. Both male (‑M) and female (‑F) versions are offered, allowing direct substitution without PCB redesign.
The datasheet covers functional description, block diagram, electrical and mechanical details, driver installation, wiring configurations, and environmental specifications, enabling designers to integrate the module into existing equipment quickly.
| USB interface speed | 12 Mbps |
|---|---|
| Maximum serial port speed | 1 Mbps |
| Operating temperature range | -40 °C to +85 °C |
| Power source | Powered by USB port (no external adapter) |
| RS‑232 signal set | TxD, RxD, RTS, CTS, DSR, DTR, DCD, RI, GND |
| USB host compatibility | USB 1.1 & 2.0 host and hub ports |
| Transmit buffer size | 128 bytes |
| Receive buffer size | 256 bytes |
The module uses FTDI drivers that can be downloaded from the FTDI website and install as a Virtual COM Port.
Install the DB9‑USB‑RS232‑M module in place of the existing male DB9 connector, then install the FTDI driver; the device will appear as a virtual COM port.
The module is designed as a DTE device; use straight‑through wiring for DCE connections and null‑modem wiring for DTE connections.
The male module provides pins DCD, RXD, TXD, DTR, GND, DSR, RTS, CTS, and RI as shown in Table 2.2 of the datasheet.
