The AD8024 is a low settling time, high-speed, high output voltage quad current feedback operational amplifier. It has high-output current capability and can drive high capacitive loads. The amplifier can run on both 5V and ±12V rails.
The AD8024 is a low‑settling‑time, high‑speed quad current‑feedback operational amplifier manufactured by Analog Devices. It can operate from a single 5 V supply up to 24 V (or dual ±12 V) and delivers up to 300 mA of output current, making it suitable for LCD column drivers, video line drivers, and high‑performance test equipment.
Key features include a 350 MHz 3‑dB bandwidth at unity gain, a 2400 V/µs slew rate, 2 mV typical input offset, 3 µA maximum input bias current, and low power consumption of 4 mA per amplifier. The device is offered in a 16‑lead SOIC package with detailed specifications for voltage swing, noise, and thermal performance.
| Bandwidth (3 dB) | 350 MHz @ G=+1 |
|---|---|
| Quiescent Current | 4 mA per amplifier |
| Input Offset Voltage (typical) | 2 mV |
| Maximum Dynamic Output Current | 300 mA |
The typical input offset voltage is 2 mV.
Each amplifier draws about 4 mA of quiescent current.
The device can deliver up to 300 mA of dynamic output current.
