This is a Philips LED monitor with a digital TV tuner, sized at 23 inches (58.4 cm). It features LED technology for natural colors, a Full HD 1080p resolution, and smart contrast and response time. The monitor also has a built-in TV tuner for viewing TV programs on the monitor, along with support for HDMI and AV inputs and powerful sound. Additionally, it includes smart sound and incredible surround features, as well as MPEG4 HDTV reception capabilities.
This manual covers the Philips 231T1LSB 23‑inch LED monitor, highlighting its Full HD 1920 × 1080 display, SmartContrast technology, and built‑in DVB‑Terrestrial TV tuner. It explains the monitor’s picture, sound, and smart mode features, as well as the convenience of automatic tuning and remote control operation.
Installation and usage information includes connectivity options (HDMI, VGA, SCART, USB, etc.), power specifications, dimensions, and accessory details. The document also lists supported video and audio formats, on‑screen display languages, and environmental operating ranges.
| Aspect ratio | Widescreen, 16:9 |
|---|---|
| Brightness | 250 cd/m² |
| SmartContrast | 20,000,000:1 |
| Contrast ratio (typical) | 1000:1 |
| Screen size | 23 inch / 58.42 cm |
| Panel resolution | 1920 x 1080 |
| Response time (typical) | 5 ms |
| Viewing angle | 170° (H) / 160° (V) |
| Output power (RMS) | 2 x SW |
| Sound system | Mono, Stereo |
| Power consumption (on mode) | 33.40 W (typical) |
| Power consumption (off mode) | 0.18 W |
| Mains power | 100‑240 V, 50/60 Hz |
| Dimensions (with stand) | 399 × 360 × 176 mm |
It has a 23‑inch (58.42 cm) diagonal screen with a Full HD 1920 × 1080 pixel resolution.
The monitor provides VGA, HDMI, PC audio in, SCART, YPbPr, CVBS, USB service port, S/PDIF out, and a common interface.
In on mode the monitor consumes about 33.4 W, while in off mode it uses roughly 0.18 W.
