The bq2407x series is a highly integrated Li-ion linear charger and system power path management device targeted at space-limited portable applications. It operates from either a USB port or AC adapter, with a high input voltage range and input overvoltage protection to support low-cost unregulated adapters. The bq2407x powers the system while simultaneously and independently charging the battery, reducing the number of charge and discharge cycles on the battery, enabling proper charge termination, and allowing the system to run with a defective or absent battery pack. It also features an NTC thermistor input, soft-start feature, integrated dynamic power management, status indication, support for up to 1.5A output current, and a small package size.
The bq2407x devices integrate a Li‑ion linear charger and system power‑path management in a compact 3 mm × 3 mm QFN package. They operate from a USB port or an AC adapter, support up to 1.5 A output, and include features such as NTC thermistor input, soft‑start, dynamic power management, and status indication. Typical applications include smartphones, PDAs, MP3 players, and other low‑power handheld devices.
The datasheet provides detailed electrical characteristics, recommended operating conditions, and pin‑function descriptions. It includes absolute maximum ratings, programmable current‑limit resistors, and layout guidelines for the RGT package, as well as safety notices and warranty information.
| Input voltage range | 4.35–26 V |
|---|---|
| Package | 3 mm × 3 mm 16‑lead QFN |
| Operating temperature range (junction) | -40 °C to 150 °C |
The devices operate with an input voltage from 4.35 V up to 26 V.
It is offered in a 3 mm × 3 mm 16‑lead QFN package.
