The product is a 3.125Gbps LVDS buffer with receive equalization, which is optimized for high-speed signal transmission over lossy FR-4 printed circuit board backplanes and balanced metallic cables.
The DS25BR110 is a single‑channel 3.125 Gbps LVDS buffer optimized for high‑speed signal transmission over lossy FR‑4 backplanes and balanced metallic cables. It offers four levels of receive equalization, on‑chip 100 Ω termination, and a small 3 mm × 3 mm 8‑LLP package.
The datasheet provides pin descriptions, electrical characteristics, jitter performance at various equalization settings, and test circuit examples. Ordering codes and configuration options are listed, along with absolute maximum ratings and recommended operating conditions.
| Data Rate | 3.125 Gbps |
|---|---|
| Package Size | 3 mm × 3 mm 8‑LLP |
| Input Common‑Mode Range | –0.3 V to +4 V |
| ESD Protection | ≥7 kV on LVDS pins |
| Power Supply Voltage | –0.3 V to +4 V |
| Receive Equalization Levels | Off, Low, Medium, High |
The DS25BR110 supports a data rate of 3.125 Gbps.
Four receive equalization levels are available: Off, Low, Medium, and High.
The device comes in a 3 mm × 3 mm 8‑LLP package.
