ASRock ConRoe1333-DVI/H Motherboard
This guide walks you through installing the ASRock ConRoe1333-DVI/H Micro ATX motherboard, from unpacking the package to connecting power, CPU, memory, and peripherals. It includes detailed diagrams of the board layout, connector locations, and recommended installation procedures.
Safety warnings, BIOS setup basics, and over‑clocking cautions are also covered, along with a brief overview of the supported CPUs, memory types, and expansion slots. The guide references additional resources on the ASRock support CD and website for driver updates and advanced configuration.
| Form Factor | Micro ATX (9.6 in x 9.6 in) |
|---|---|
| CPU Socket | LGA 775 |
| SATA II Connectors | 4 x SATAII 3.0 Gb/s |
| PCI Express Slots | 1 x PCIe x16, 1 x PCIe x1 |
The board provides four SATA II 3.0 Gb/s connectors.
It supports up to 4 GB of DDRII memory.
A 20‑pin ATX power connector is used.
The motherboard uses an LGA 775 (775‑Pin) socket.
