This document provides some application information on how to use the Premium 10501.
The Premium 10501 is a complete CD‑engine starter kit that includes a PCB‑mounted CD mechanism, cables and DSA control software. The manual describes the system overview, connector pinouts, configuration options and the DSA control interface for integration into high‑end audio, video and jukebox applications.
Power requirements, audio performance tips, wiring diagrams and a problem‑solving section guide users through installation, operation and servicing of the module.
| Laser power | 375 µW |
|---|---|
| +5 V supply current (normal play) | 120 mA |
| +9 V supply current (normal play) | 40 mA |
| +9 V peak current (spin up/down) | 600 mA |
| Audio output level | 1.5 V eff |
| Audio output impedance | 110 Ω |
| Optional clock output | 16 MHz |
The CD engine PCB requires two external power supplies, one for +5 V and one for +9 V.
It allows the laser to be switched off, for example when a cabinet door is opened, improving safety.
Wait at least 1 second after the +5 V is applied before sending any DSA commands.
The measured SNR is about 97 dB.
