This document presents the thermal design guide for the Fortimo LED SLM platform, including thermal specifications, how to measure Tcase at its critical temperature point Tc, thermal interface materials (TIM), designing passive and active cooled luminaires, and complementary partners for thermal solutions.
The Thermal Design Guide V2.3 provides detailed thermal specifications and design recommendations for the Philips Fortimo LED SLM platform. It includes guidance on measuring the critical temperature point (Tcase), selecting thermal interface materials (TIM), and designing both passive and active cooling solutions.
The document also lists complementary thermal‑solution partners, presents thermal impedance requirements for each SLM model, and supplies contact information for regional support. It is intended for engineers designing luminaire systems that incorporate Fortimo LED modules.
