ASRock Z77 Pro3 Manual(1)

About this manual

This guide covers the unpacking of the Z75 Pro3 motherboard, the required components, and the installation procedure for ATX cases. It includes detailed diagrams of the rear I/O panel, power connectors, and jump‑wire settings.

The document also describes the BIOS features, supported CPUs, memory types, storage interfaces, and USB/HDMI capabilities, helping users configure the system for optimal performance. This manual is written in Chinese.

What's inside

• 包装 (Package Contents)
• 主概规格 (General Specifications)
• 后面板和 I/O 接口 (Rear Panel and I/O)
• BIOS
• 跳线设置 (Jumpers and CMOS)
• 安全与保修信息 (Safety and Warranty)

Specifications

Frequently asked questions

What CPU socket does the Z75 Pro3 motherboard support?

It supports the LGA1155 socket for Intel Core i7, i5 and i3 processors.

How many SATA3 ports are available on the board?

The board provides two SATA3 6 Gb/s ports that support RAID and NCQ.

What type of BIOS is used on the Z75 Pro3?

It uses a 64 Mb AMI UEFI Legacy BIOS with a graphical user interface.
