This guide describes the working principle of the temperature transmitter, which senses temperature, processes the signal and compares it to a set point to generate PNP or NPN switching outputs. It also highlights the simple structure, low power consumption, high measurement accuracy and robust mechanical design.
Physical dimensions, output options, electrical ratings, environmental limits and safety certifications are listed, along with detailed technical parameters such as load current, accuracy, temperature range and insulation resistance. This manual is written in Chinese.
| Load Current | 200 mA |
|---|---|
| Accuracy | ±0.1 °C |
| Medium Error Range | -40 °C to +100 °C |
| Insulation Resistance | >100 MΩ (500 VDC) |
| Reliability (MTBF) | ≥15,000 hours |
The maximum load current is 200 mA.
The accuracy is ±0.1 °C.
